product name:
LG660DSx2000 lathe
product num:
LG660DSx2000 lathe
Email:
Features and Benefits:
· 7.5KW main motor
· 400mm width of bed
· 24 spindle speeds from 10 to 1400 RPM
· D1-8 camlock spindle with 80mm bore
· Spindle hardened & precision ground
· Bed made of fine grain high tensile cast iron
· Bedways hardened & precision ground
· Gears & shafts hardened & precision ground
· 4-way rapid traverse on carriage feed
· Headstock with mechanical clutch
· Automatic lubrication system in headstock & feedbox
· Handwheel automatically disengaged during longitudinal feed

Specs:
Model LG660DS x 2000
Swing over bed 660mm
Swing over cross slide 400mm
Swing over gap 880mm
Distance between centers 2000mm
Width of bed 400mm
Taper of spindle hole Ø90mm  1:20
Spindle nose D8 camlock
Spindle speed range (No.) 10-1400rpm (24)
Spindle bore diameter 80mm
Longitudinal feed rate per revolution 0.028-6.33mm
Cross feed rate per revolution 0.014-3.16mm
Metric threads range (No.) 1-192mm (44)
Inch threads range (No.) 2-24TPI (21)
Max. travel of cross slide 370mm
Max. travel of compound rest 140mm
Tailstock spindle diameter 75mm
Tailstock spindle travel 150mm
Taper of tailstock spindle hole Morse No. 5
Main motor 7.5KW
Power supply 380V/3Ph/50Hz

Please send inquiry to: tonywang@mec.com.cn
